AutoCAD Electrical

AutoCAD Electrical is a specialist control panel of Autodesk. The AutoCAD electrical software increases the productivity levels of up to 80% when compared to the traditional methods of 2D drafting. The sound knowledge of the software can enable the electrical engineers to exploit the surplus availability of specially developed electrical drafting tools to enhance the productivity.

Course Objectives

The AutoCAD Electrical course will focus on the overview of AutoCAD electrical with emphasis on naming conventions; the use of symbol and their libraries, generation, and insertion of PLC layout modules, and organization of PLC database files. The course will also teach the students about generating a bill of materials reporting, creating PLC I/O drawings from spreadsheets, wire numbering, and component tagging.

The AutoCAD Electrical course through CADD Centre will help the students master the concepts and capabilities of AutoCAD Electrical as listed below:

The AutoCAD Electrical course at CADD Centre is taught by skilled trainers who provide customized training and mentoring. The course completion certificate for AutoCAD Electrical from CADD Centre is universally recognized and valued.

The students have a very good opportunity as an electrical design engineer if they possess the skills of AutoCAD Electrical. An individual at such a post can earn around $65,840 per year. Also, the pay for this job increases steadily for experienced candidates.

Who should be aiming for the course?

The individuals who want to take up the course must have a good working knowledge of AutoCAD software, and they must be well acquainted with the terminologies used in the electrical domain.

Fee $225
Duration 4 years
Credit 180
Semester 12
Quizzes 2
Pass Parcentages 80%
Maximum Retakes 5
Rating 4.9(80 reviews)
